Copper Sheets Suppliers in India, #6313
Nexim Alloys is the most dominating manufacturers, stockists, supplier & exporter of copper Sheets. These copper sheets do have its applications in furniture, electrical applications, research & development, arts & craft and more.
Owner
Description
These Sheets has its features like good mechanical properties, corrosion & abrasion resistant, easy fibre brazing & welding, good conductor of heat & electricity, long lasting strength & also features like excellent dimensional control & high crack resistance which makes these materials easy to cut, machine and otherwise form. These Sheets has its application in industries like pressure vessels, steam condensers, heat exchangers, welded tanks, ship building, oil exploration, missile components & more. The Sheets are made of best quality raw material & do match national & international quality standard & this helps us to have high demand in the market from our customers. The prices for these Sheets are completely customer friendly & market oriented. These Sheets are manufactured in different size, dimension & thickness & are delivered to customers as per their need & requirement. When it comes to packaging it is done with great care because we know the challenges faced while import & export of product hence we see through it that the product is delivered in good conditions without any damages.
Features:
- Strong Corrosion Resistance
- Both Electrical and Thermal Conductivity
- Malleability of the metal with an Ease of Fabrication
Copper Sheet, DOW, DHP & ETP Size Range :
Standard SizeThickness1000 × 2000 mm1.2 mm to 16 mm1250 × 1250 mm1.2mm to 25 mm1250 × 2500 mm1.2 mm to 12 mm2’x4’,16’’x48’’,14’’x48’’0.3 mm to 25 mm
Chemical Composition of Copper :
MaterialNormal Composition
Nearest Relevant Composition Specification
Electrolytic tough Pitch H.C. Copper99.92% Min. CuC 101Cu ETP 1337H 3100 C 2100Phosphorous Deoxidized Copper ( DONA)99.92% Min. Cu P.0.0134-0.05C 106Cu DHP 1337H 3100 C 122
Specifications
MaterialTensile temper strength elongation N/mm% on 50mm
Vickers HardnessComplies with or falls within ISOJIS
'O'210 min 35 min55 max
Electrolytic ToughM210 min 35 min65 maxCu ETPH 3100Pitch H.C Copper½ H210 min 10 min70 to 95ISO : 1337C 1100
H290 min90 Min
'O'210 min 35 min55 max
PhosphorousM210 min 35 min65 maxCu DHPH 3100Deoxidised Copper½ H240 min 10 min70 to 95ISO : 1337C 1220
H290 min90 Min
'O' : Annealed Condition
M : 1/4 Hard
1/2 : Half Hard
H : Full Hard
* : Electrical conductivity at 20°. Cel(% IACS) - 100-101 (For Cu ETP 'O' temper)
